SSR-50DA 50Amp 380V Solid State Relay

SSR-50DA 50Amp 380V Solid State Relay

Easily driven from Arduino digital output pin.

See more details, applications on our WIKI here:

- Solid State Relay

- Description:Rated Load Current-50A

- Model:SSR-50DA Terminal Type

- Rated Load Current: 50A

- Input

- Operating Voltage:3~32VDC

- Min. ON/OFF Voltage:ON>2.4V , OFF<1.0V

- Trigger Current:7.5mA / 12V

- Control Method:Zero Cross Trigger

- Output

- Operating Voltage:24~380VAC

- Min. Back Voltage:600 VAC (Repetive)

- Voltage Drop:1.6V / 25°C

- Max. Pulse Current:275A

- Leakage Current:3.0mA

- Response Time:ON<10ms , OFF<10ms

- General Data

- Dielectric Strength:Over 2.5KVAC / 1min.

- Isolation Strength:Over 50MO / 500VDC

- Operating Temperature:-20°C ~ +80°C

- Housing Material:Intensive ABS

- Weight:139g

Please see this about Precautions for using Solid State Relays

Please Read This Electrical Safety / Disclaimer page before using the relay board in this product.
